PRODUCT'S DETAIL
SLICKSPRAY MK-70
Previous
|
Overview
SLICKSPRAY MK-70 SYSTEM is a compact dispersant spraying system with 4 lances or spray gun complete with wheels to make transportation easier and can be operated on vessels.
Login to see prices | unit(s)
Description
Features :
- Suitable for spraying neat or diluted dispersant
- The spray pump MK-70 material is stainless steel tubing or mild steel
- The lance supplied is to be used simultaneously
- Fixed proportioning eductor is designed to tolerate various viscosities of dispersant and water. This eductor will produce a proportional mixture of 10% dispersant to 90% water or 100% dispersant
- Equipped with an automatic Shutdown Valve and a Spark Arrestor for added safety features
- Optional 2×3 m arm for onshore or 2×6 m arm for offshore or based on customer’s request
Technical Data :
Trolley Model
| Designed For | Portable use in harbour and jetty |
| Capacity | Sea water / fresh water and chemical min. 22 Gpm (83 lpm) |
| Engine | Min. 3 kW diesel engine with recoil hand start |
| Pump | Self-priming roller vane type, super roller or teflon material liquid jet type to dilute concentrate application |
| Nozzle | Optimum droplet size is achieved by special nozzle designs. Neat or diluted dispersant can be used |
| Mixture Control | Fixed proportioning flow control is designed to tolerate various viscosity of dispersant and water, this flow control will produce proportional mixture of 10% dispersant to 90% water or 100% dispersant |
| Optional | – |
| Safety Devices | Automatic shutdown valve and spark arrestor |
| Standard Accessories | Hose sets, guns sprayer |
Frame Model
| Designed For | To be fixed on board of RIB or other boat |
| Capacity | Sea water / fresh water and chemical min. 22 Gpm (83 lpm) |
| Engine | Min. 3 kW diesel engine with recoil hand start |
| Pump | Self-priming roller vane type, super roller or teflon material liquid jet type for dilute concentrate application |
| Nozzle | Optimum droplet size is achieved by special nozzle designs. Neat or diluted dispersant can be used |
| Mixture Control | Fixed proportioning flow control designed to tolerate various viscosity dispersant and water, this flow control will produce proportional mixture of 10% dispersant to 90% water or 100% dispersant |
| Optional | Spray arm to be installed on vessels |
| Safety Devices | Automatic shutdown valve and spark arrestor |
| Standard Accessories | Hose sets, guns sprayer |
